2U4N configuration installation guidelines
Assuming installation is into an empty rack, always begin component installation at the
bottom of the cabinet and install upward. Install components at the lowest available
space for that component type.
The quantities of components that can be installed in a cabinet are dependant on the
type of power distribution units installed in the cabinet.
The following sections provide the component stack up as applicable to the type of
power distribution for your installation:
l
In cabinets with single-phase power distribution, refer to Installation in cabinets
with single-phase power distribution on page 32
l
In cabinets with
3-phase delta or 3-phase wye power distribution, refer to
Installation in cabinets with 3-phase delta or 3-phase wye power distribution on
page 33
Installation in cabinets with single-phase power distribution
If you are installing the system in a cabinet with single-phase power distribution, the
maximum stack up will be as follows:
Table 6 Maximum stack up in cabinets with single-phase power
distribution
Component
Function
Description Quantity Cabinet U Space
Data Server Quanta 2U4N Server 14 2 - 17, 26 - 31, and 34 - 39
Management Server Kylin 1U Server 1 18
Management Switch Arista 7010T-48 2 19 and 21
Data Switch (A and B) Arista 7050-128 2 22 - 25
Data Switch (C and D) Arista 7050-64 2 32 - 33
2U4N Configuration Equipment Installation
32 VxRack Node Hardware Installation Guide
