16
|
Installation
UPS Communication Bay
IEC-C20 Input
Connector
USB Port
Two IEC 320-C13 Receptacles
(Load Segment 2)
REPO Ports
RS-232 Port
Ground Screw
Six 5-15/5-20 and Two
IEC 320-C19 Receptacles
(Load Segment 1)
EBM Connector Cover/Strain
Relief Bracket
Figure 6. 1920W/120V, 1500W/100V Rear Panel
UPS Communication Bay
IEC-C14 Input
Connector
USB Port
Two IEC 320-C19
Receptacles
(Load Segment 2)
REPO Ports
RS-232 Port
Ground Screw
EBM Connector Cover/Strain
Relief Bracket
Six IEC 320-C13
Receptacles
(Load Segment 2)
Two IEC 320-C13
Receptacles
(Load Segment 1)
Figure 7. 1920W, 230V Rear Panel
