Dell 1409X - Using the Control Panel; Control Panel Button Functions

Using Your Projector 19
Using the Control Panel
Screen
(Diagonal)
Max. 25.2"
(64.1cm)
75.7"
(192.3cm)
126.2"
(320.5cm)
176.7"
(448.7cm)
227.1"
(576.9cm)
302.8"
(769.2cm)
Min. 22.89"
(58.3cm)
68.8"
(174.8cm)
114.7"
(291.4cm)
160.6"
(407.9cm)
206.5"
(524.5cm)
275.3"
(699.3cm)
Screen
Size
Max.
(WxH)
20.2"X15.1" 60.6" X45.4" 101.0" X 75.7" 141.3" X106" 181.7" X 136.3" 242.3" X 181.7"
(51.3cm X
38.5cm)
(153.8cm X
115.4cm)
(256.4cm X
192.3cm)
(359.0cm X
269.2cm)
(461.5cm X
346.2cm)
(615.4cmX
461.5cm)
Min.
(WxH)
18.3" X 13.7" 55.1" X 41.3" 91.8" X 68.8" 128.5" X 96.4" 165.2" X 123.9" 220.3" X 165.2"
(46.5cm X
34.9cm)
(139.9cm X
104.9cm)
(233.1cm X
174.8cm)
(326.3cm X
244.8cm)
(419.6cm X
314.7cm)
(559.4cm X
419.6cm)
Hd
Max. 2.27"
(5.8cm)
6.81"
(17.3cm)
11.36"
(28.8cm)
15.9"
(40.4cm)
20.44"
(51.9cm)
27.26"
(69.2cm)
Min. 2.06"
(5.2cm)
6.19"
(15.7cm)
10.32"
(26.2cm)
14.45"
(36.7cm)
18.58"
(47.2cm)
24.78"
(62.9cm)
Distance 3.3' (1.0m) 9.8' (3.0m) 16.4' (5.0m) 23.0' (7.0m) 29.5' (9.0m) 39.4' (12.0m)
* This graph is for user reference only.
1 LAMP warning light If the LAMP light is solid amber, replace the
lamp. If the LAMP light is blinking amber, the
lamp driver or color wheel have failed and the
projector automatically shuts down. If the
problem persists, contact Dell™.
1
3
5
2
7
10
10
9
4
8
6
