Dell 1409X - Connecting a Computer Using a DVI-D Cable

Connecting Your Projector 9
Connecting a Computer using a DVI-D Cable
NOTE: The USB cable and DVI-D cable are not provided by Dell.
1 Power cord
2 DVI-D cable
3 USB to USB cable
