Connecting Your Projector 7
2
Connecting Your Projector
CAUTION: Before you begin any of the procedures in this section, follow the
Safety Instructions as described on page 6.
1 DVI-D input connector
2 VGA-A output (monitor loop-through)
3 VGA-A input (D-sub) connector
4 VGA-B input (D-sub) connector
5 S-video connector
6 Composite video connector
7 Audio input connector
8 Audio output connector
9 USB remote connector
10 RS232 connector
11 Security cable slot
12 Power cord connector
21345678910
11
12
Dell 1409X
USB
Remote
RS-232
DVI-D In
S-Video In
Video In
VGA - B
In
Audio Out
Audio In
VGA - A
Out
VGA - A
In
