Dell 1907FPf - Block

Service Manual
20
1907FPf Disassembly Block
(I,Cross,M3*6,Zn-Cc)*4 (LPL,AUO)
or
(I,Cross,M3*4,Zn-Cc)*4 (Samsung)
(P,Cross,M4*10,BLACK-NL)*4
LP1903 DISASSEMBLY BLOCK
rubber silicon thermal conduct*2
RCM 19*1
vesa release button*1
FRONT BEZEL ASSY*1
button fuction key*1
logo plate*1
front bezel*1
vent right*1
back cover*1
BACK COVER ASSY*1
vent left*1
kensington lock*1
STAND ASSY*1
CHASSIS ASSY*1
keypad support*1
usb cover*1
usb board*1
light cover*2
panel*1
mylar for panel*1
power board*1
I/F board*1
mylar for chassis*1
chassis*1
fix-plate2*1
slide*1
spring*2
keypad board*1
PANEL ASSY*1
(P,cross,T.T-3*4,Zn)*1
FFC-CABLE*1
TAPE, ACE*1 (85x28mm)
(P,Cross,W/WAS,M3*6,Zn-Cc)*3
(BOLT,#4-40,NI)*4
(P,Cross,W/WAS,M3*6,Zn-Cc)*3
(B,Cross,W/W(T)M4*6,Zn)*1
(I,Cross,M3*6,Zn-Cc)*2
(P,Cross,W/WAS,M3*6,Zn-Cc)*1
(I,Cross,M3*4,Zn-Cc)*1
FINAL ASSY*1
fix-plate2*1
EMI clip*4
(P,cross,T.T-3*4,Zn)*1
Tape ACE*3(LPL) or 2(AUO)
foam,poron,adhesive*1
