Dell 1907FPf - Page 43

Service Manual
42
Chapter 7- Bill Of Material
Item Component no. Object description Quantity
8192037GD010R LP1903-7G2(B),W/O SPK,US
1 714075370000R ASSY,FINAL(G),W/O SPK,LP1903-7G2 1
2 506140005800R LABEL,BARCODE, LE1X13 1
3 506250008000R LBL,AGENCY,TCO99, LP1903 1
4 506431001900R FILM,PROTECTION,PRINTED,DELL,LE1913 1
5 506380001400R TAPE,3M-897,12x45000mm 0.156
6 506280004600R POSTER,QUICK SETUP,WEAST, LP1903 1
7 506070104500R MNL USER'S(CD), LP1903 1
8 506170600300R GUIDE,PRODUCT INFORMATION,LP1X03 1
9 506040007700R CUSHION,EPS,TOP, LP1903 1
10 506120301800R BAG,EPE+PE,L525xW700, LP1X03 1
110 506120301900R BAG,EPE+PE,L580xW500, LP1X03 1
120 506020009600R CARTON,DELL(WWW), LP1903 1
130 506440001500R LABEL,BLANK,165.1*101.6mmFOR CARTON 1
140 506380001500R TAPE,WRAPPING TYPE,3M-373,914000x72mm 0.13
150 713000069500R ASSY PACK,AIR CARGO, LP1903
150 713000069600R ASSY PACK,40HQ, LP1903 1
160 453070800150R PWR CORD 10A/125V BLK 6FT UL/CSA,SVT 3Cx 1
170 453010100140R CABLE,D-SUB 15P MALE 6FT BLACK/BLUE,CD15 1
180 453030300160R CABLE,DVI-D 24P MALE 2M(BLACK) RoHS 1
190 453030300230R CABLE,USB 2.0,2M BLACK,RoHS 1
200 506040007710R CUSHION,EPS,MIDDLE, LP1903 1
210 506040007720R CUSHION,EPS,BOTTOM, LP1903 1
714075370000R ASSY,FINAL(G),W/O SPK,LP1903-7G2
10 714085370000R ASSY,PANEL,W/O SPK,LP1903-7G2 1
30 509116610510R SCREW,P,CROSS,M4*10,BLACK-NL(NYLOK) 4
50 714030004800R ASSY,BEZEL, LP1903 ROHS 1
60 714050004800R ASSY,BACK COVER, LP1903 ROHS 1
70 714010004800R ASSY,STAND, LP1903 ROHS 1
713000069600R ASSY PACK,40HQ, LP1903
10 506432001800R SLIP SHEET,L1310xW100xH100mm, LP1903 ROH 3.3
20 506037005000R CARDBOARD,COVER,1310x1000x70x3mm,LP1903 6.7
30 506039003500R CORNER PAPER,1190x50x50xT3mm,ROHS 13.3
40 506431000300R FILM,PE 500mmx900M ROHS 0.085
714085370000R ASSY,PANEL,W/O SPK,LP1903-7G2
10 505040202600R INSULATOR,MYLAR,PANEL ,LP1903 ROHS 1
30 509146306202R SCREW,P,CROSS,W/WAS(7.8),M3*6,Zn-Cc 7
40 509476606100R SCREW,B,CROSS W/W(T)M4*6,ZnROHS 1
50 509016306200R SCREW,I,CROSS,M3*6,Zn-Cc 6
60 509000001000R BOLT,#4-40x12.5,Ni ROHS 4
70 502080100100R SUPPORT,KEYPAD, LP1703 ROHS 1
