Service Manual
110 411020046410R DIO MW4148-G 75V/0.15A (MMC) DO-213AA Ro MITSUBISHI,
110 411023004020R DIO MM4148 75V/0.15A SMD(FEC) DO-213AA,R
FRONTIER,
110 411020046270R DIO RLS4148 75V/0.15A (ROHM) LL-34 RoHS ROHM,
120 411020026090R DIO BAV99 350mW 75V SOT-23(PEC RoHS PANJIT,
120 411020026210R DIO BAV99 350mW 70V SOT-23(PHI RoHS PHILIPS,
120 411020026390R DIO BAV99,SOT-23(INFINEON)RoHS
4
INFINEON,
D304,D328,D329,D330,
120 411020026020R DIO BAV99-LF 350mW 70V SOT-23 (FEC)RoHS FRONTIER,
130 432002500140R ESD SMD(0603) 0.055pF/24V(LITTELFUSE)RoH
3
LITTELFUSE,
D315,D316,D317,
130 432002500010R ESD SMD(0603) 0.2pF/30V(INPAQ) EGA10603V 6 INPAQ,
EP901,EP902,EP903,EP904,EP905,EP906,
140 432002312113R BEAD CORE SMD(0805)120Ω 3A PBY201209T-1 6 CHILISIN,TAI-TECH,TECSTAR,
L407,L409,L410,L415,L901,L903,
150 432002319041R BEAD CORE SMD(0603)19Ω 500mA, SBK160808 3 CHILISIN,TAI-TECH, L309,L310,L311,
160 432002330140R BEAD CORE SMD(0603)300Ω 200mA RoHS 3 CHILISIN,TAI-TECH,TECSTAR, L406,L411,L416,
170 432002360111R BEAD CORE SMD(0805) 600Ω 2A PBY201209T- 5 CHILISIN,TAI-TECH,TECSTAR, L501,L413,L414,L412,L404,
180 432002330142R BEAD CORE SMD(0603)300Ω 2A PBY160808T-3 CHILISIN,TAI-TECH,
190 410500046210R XSTR PMBT3906 PNP 200MA,40V SOT23(PHILIP PHILIPS,
190 410500046180R XSTR MMBT3906LT1G PNP 200mA 40V SOT23(ON
1
ON SEMI,
L905,
190 410500046130R XSTR MMBT3906 PNP SOT-23(INFIN EON)RoHS INFINEON,
200 410500044120R XSTR SI2301BDS-T1-E3 P-CH SOT23 (VISHAY) VISHAY,
200 410500044270R XSTR AO3401L P-CH(ALPHA-OMEGA) SOT23 RoH
1
AOS,
Q401,
200 410060004210R XSTR PMV65XP P-CH SOT23(PHILIP S)RoHS PHILIPS,
210 410500045210R XSTR PMBT3904 NPN 200MA,40V SOT23(PHILIP PHILIPS,
210 410500045140R XSTR MMBT3904LT1G NPN 200MA 40V SOT23(ON ON SEMI,
210 410500045130R XSTR MMBT3904 NPN SOT-23(INFIN EON)RoHS
3
INFINEON,
Q501,Q902,Q903,
210 410500045241R XSTR MMBT3904 NPN 200mA 40V SOT23(FAIRCH 3 FAIRCHILD, Q502,Q901,Q601,
220 414916010150R RES SMD (0603) 100Ω J,RT RoHS REV:A 15 TA-I,WALSIN,YAGEO,
R301,R302,R304,R308,R309,R310,
R311,R315,R316,R324,R326,
R328,R329,R404,R406,
230 414916750910R RES SMD (0603) 75Ω F,RT RoHS REV:A 3 TA-I,WALSIN,YAGEO, R305,R306,R307,
240 414916047250R RES SMD (0603) 4.7KΩ J,RT RoHS 22 TA-I,WALSIN,YAGEO,
R312,R313,R314,R323,R325,R407,R408,
R409,R410,R412,R413,R416,R417,R418,
R420,R426,R901,R903,R915,R337,R602,
R501,
250 414916022250R RES SMD (0603) 2.2KΩ J,RT RoHS 3 TA-I,WALSIN,YAGEO, R320,R319,R601,
260 414916560910R RES SMD (0603) 56Ω F,RT RoHS REV:A 3 TA-I,WALSIN,YAGEO, R322,R332,R334,
270 414916249010R RES SMD (0603) 249Ω F,RT,RoHS 1 TA-I,WALSIN,YAGEO, R401,
280 414916010350R RES SMD (0603) 10KΩ J,RT RoHS 10 TA-I,WALSIN,YAGEO,
R415,R423,R910,R916,R918,R421,R422,
R432,R911,R502,
290 414916010250R RES SMD (0603) 1KΩ J,RT RoHS REV:A 2 TA-I,WALSIN,YAGEO, R403,R419,
300 414916000050R RES SMD (0603) 0Ω J,RT RoHS 3 TA-I,WALSIN,YAGEO, R424,R425,R913,
To Next Page
