Dell 1907FPf - Page 53

Service Manual
52
220 410500050120R XSTR 2N7002K ESD N-C SOT-23, (VISHAY)RoH VISHAY,
230 410500070290R XSTR AP9971GM,N-CH,SO8(APEC) RoHS 2 APEC, Q7,Q6,
230 410500060270R XSTR AO4826L DUAL N-CH SOIC8 (AOS)RoHS AOS,
240 411020026210R DIO BAV99 350mW 70V SOT-23(PHI RoHS 5 PHILIPS, ZD1,ZD2,ZD3,ZD5,ZD6,
240 411020026020R DIO BAV99-LF 350mW 70V SOT-23 (FEC)RoHS FRONTIER,
250 412000377630R IC OZ9936GN SOIC8(O2 MICRO)RoHS 1 O2, U1,
260 490582100100R PCB,CONTROL(INVERTER), LP1X03 1
EXPRESS,GOODWELL,SHENG
HUA,WELFARE,
790582141000R PCBA,CONTROL/B(PWR A-D),SMD, LP1X03
10 419311030060R C SMD(0603) X7R 0.01uF/50V K RoHS 1 DARFON,TDK,WALSIN,YAGEO, C858,
20 419311020060R C SMD(0603) X7R 1000PF/50V K RoHS 1 DARFON,TDK,WALSIN,YAGEO, C870,
30 419304700560R C SMD(0603) NPO 47PF/50V J RoHS 1 DARFON,TDK,WALSIN,YAGEO, C867,
40 411101122050R ZENER BZV55-C22 SOD80C(PHILIPS RoHS 1 PHILIPS, D856,
40 411100622050R ZENER 22V ZMM55-C22-LF DO-213A A(FRONTIE FRONTIER,
50 414908150910R RES SMD (0805) 15Ω F,RT RoHS 1 TA-I,WALSIN,YAGEO, R856,
60 414916261210R RES SMD (0603) 26.1KΩ F,RT RoHS 1 TA-I,WALSIN,YAGEO, R858,
70 414908047050R RES SMD (0805) 47Ω J,RT RoHS 1 TA-I,WALSIN,YAGEO, R861,
80 414916000050R RES SMD (0603) 0Ω J,RT RoHS 1 TA-I,WALSIN,YAGEO, R887,
90 412000297020R IC SG6841SZ SOP-8(SG)RoHS 1 SG, U850,
100 490582100200R PCB,CONTROL(PWR A-D), LP1X03 1
EXPRESS,GOODWELL,SHENG
HUA,WELFARE,
790582142000R PCBA,CONTROL/B(PWR D-D),SMD, LP1X03
10 419311040070R C SMD(0805) X7R 0.1uF/50V K RoHS REV:A 2 DARFON,TDK,WALSIN,YAGEO, C802,C803,
20 419312240070R C SMD(0805) X7R 0.22uF/50V K RoHS 1 DARFON,TDK,WALSIN,YAGEO, C804,
30 419313310070R C SMD(0805) X7R 330pF 50V K RoHS 1 DARFON,TDK,WALSIN,YAGEO, C805,
40 414908102110R RES SMD (0805) 1.02KΩ F,RT, RoHS 1 TA-I,WALSIN,YAGEO, R801,
50 414908562110R RES SMD (0805) 5.62KΩ F,RT, RoHS 1 TA-I,WALSIN,YAGEO, R802,
60 414908240210R RES SMD (0805) 24KΩ F,RT,RoHS 1 TA-I,WALSIN,YAGEO, R803,
70 412000447770R IC AIC1577PSTR SOP-8(AIC)RoHS 1 AIC, U802,
80 490582100300R PCB,CONTROL(PWR D-D), LP1X03 1
EXPRESS,GOODWELL,SHENG
HUA,WELFARE,
790581500000R PCBA,KEYPAD BOARD, LP1X03
10 430602680020R SW METAL DOME 180gf 5P,RoHS 1 FOXCONN,HUA-JIE, METAL DOME,
20 430631080080R WFR 1.25mm 8P 180° 4300-08 RoHS 1 FOXCONN,HEIGHTEN,JOWLE, J1,
30 790581540000R PCBA,KEYPAD/B,SMD, LP1X03 1
11 506380200101R TAPE,TWIN ADHESIVE,96x6mm,LP1X03 1 KAIDA,O'FRIEND,
790581540000R PCBA,KEYPAD/B,SMD, LP1X03
10 490581500100R PCB,KEY PAD, LP1X03 1 GOODWELL,WELFARE,
20 411070044500R LED SMD 1612 Y/G KPTB-1612SYKC GKC-SZ(KI 1 KINGBRIGHT, LED1,
