Appendix 97
Temperature range:
Operating 0° to 60°C(32° to 140°F) (8 cell)
0° to 35°C(32° to 95°F) (12 cell)
Storage –20° to 60°C (–4° to 140°F) (8 cell)
–40° to 65°C (–40° to 149°F) (12 cell)
AC Adapter
Input voltage 100 to 240 VAC
Input current (maximum) 2.5 A
Input frequency 50 to 60 Hz
Output current 7.7 A (maximum at 4-second pulse),
6.7 A (continuous)
Output power 130 W
Rated output voltage 19.5 VDC
Dimensions:
Height 36 mm (1.42 inches)
Width 65 mm (2.56 inches)
Length 169.5 mm (6.67 inches)
Weight (with cables) 0.75 kg (1.65 lb) (1 lb and 10.6 oz)
Temperature range:
Operating 0° to 35°C (32° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Physical
Height
14.1-inch display 43.7 mm (1.72 inches)
15-inch display 46.5 mm (1.83 inches)
Width 274 mm (10.8 inches)
Depth 328 mm (12.9 inches)
Battery (continued)
