Component Secured to Screw type Quantity Screw image
Hinges Palm-rest assembly M2.5x2.5 2
Power-adapter port System board and palm-
rest assembly
M2x3 1
Power-button board Palm-rest assembly M2x3 3
USB Type-C port
bracket
System board M2x3 1
System board Palm-rest assembly M2x2 5
Keyboard bracket Palm-rest assembly M1.2x2.2 8
Keyboard Palm-rest assembly M1.2x1.9 33
15
