Removing the base cover
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Loosen the three captive screws on the base cover.
2 Remove the six screws (M2.5x10) that secure the base cover to the palm-rest assembly.
3 Remove the two screws (M2.5x10) from the back that secure the base cover to the palm-rest assembly.
4 Using a plastic scribe, pry the base cover from the computer base.
16
