Removing the touchpad
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the battery (half-length) or the battery (full-length), whichever applicable.
Procedure
1 Open the latch and disconnect the touchpad cable from the system board.
2 Remove the four screws (M2x2.5) that secure the touchpad to the palm-rest assembly.
3 Slide the touchpad along with its cable at an angle and lift the touchpad o the palm-rest assembly.
59
