Replacing the solid-state drive/Intel Optane memory
module
Enable the Intel Optane memory after you replace the Intel Optane memory module. For more information about enabling the
Intel Optane memory, see Enabling Intel Optane memory.
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
CAUTION: Solid-state drives are fragile. Exercise care when handling the solid-state drive.
Procedure to replace M.2 2230 solid-state drive
NOTE: This procedure applies only to systems shipped with a M.2 2230 solid-state drive installed.
NOTE: Depending on the conguration ordered the system may have up to two M.2 solid-state drives installed.
Supported card congurations per M.2 solid-state drive slot:
• M.2 2230 solid-state drive + solid-state drive bracket
• M.2 2280 solid-state drive
• M.2 2280 Intel Optane
NOTE: For solid-state drives above 512 GB or Intel Optane above 118 GB a thermal shield is required for optimal
heat dissipation and is installed in the computer when these congurations are ordered. If these congurations are
installed After Point-of-Sale (APOS), contact Dell support for the thermal shield.
NOTE: Depending on the number of M.2 solid-state drives installed at Point-of-Sale, the thermal shield installed in
the computer may be a full shield or a half shield. If two M.2 solid-state drives are installed After Point-of-Sale
(APOS) contact Dell support for the full thermal shield.
1 Place the M.2 2230 solid-state drive on the M.2 2230 solid-state drive bracket.
2 Replace the screw (M1.6x2) that secures the M.2 2230 solid-state drive to the M.2 2230 solid-state drive bracket.
3 Align the notch on the M.2 2230 solid-state drive with the tab on the M.2 solid-state drive slot on the system board.
4 Slide the M.2 2230 solid-state drive along with the bracket into the M.2 solid-state drive slot on the system board.
