About the Printer 41
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_AIO_UG_FM\Mioga_AIO_UG_FM\section04.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
NOTICE: To avoid irregular screen image or malfunctioning of your printer,
avoid placing the printer in direct sunlight with the single sheet feeder opened.
Rear View
Space Requirements
Provide enough room to open the printer trays, covers, and optional accessories,
and for proper ventilation.
6 Belt Unit 12 Operator Panel
1 Automatic Document Feeder (ADF) 6 "Blue" Plug
2 Control Board Cover 7 Power Connector
3 Control Board 8 Ethernet Port
4 Phone Connector 9 Wireless Adapter Socket
5 Wall Jack Connector 10 USB Port
