Troubleshooting Guide 701
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_AIO_UG_FM\Mioga_AIO_UG_FM\section31.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
Ghosting
Action Yes No
1 Locate the cause of the problem using the Ghost
Configuration Chart.
a
Launch the Tool Box, and click
Chart Print
on the
Diagnosis
tab.
b
Click the
Ghost Configuration Chart
button.
The Ghost Configuration Chart is printed.
Is the type of the problem identified?
Proceed to the
action
corresponding
to the type of
ghosting.
Positive ghost -
2a
Negative ghost
- 2b
Contact Dell.
2a Replace the PHD unit if you have a spare unit.
a
Replace the PHD unit. See "Replacing the
Print Head Device (PHD) Unit" and
"Installing a PHD Unit."
b
After you replace the PHD unit, click
Chart
Print
on the
Diagnosis
tab.
c
Click the
Ghost Configuration Chart
button.
The Ghost Configuration Chart is printed.
Does this solve your problem?
The task is
complete.
Contact Dell.
2b If you are using non-recommended print media,
use the print media recommended for the printer.
Does this solve your problem?
Go to action 3. Go to action 2a.
