Bottom View
Label
Description
1
AC power cord connector
2
DVI connector
3
VGA connector
Monitor Specifications
Flat Panel Specifications
*[E1911] color gamut (typical) is based on CIE1976 (80%) and CIE1931 (72%) test standards.
Model
Dell E1911 monitor
Screen type
Active matrix - TFT LCD
Panel type
TN
Screen dimensions
19 inches (19-inch viewable image size)
Preset display area
408.24 (H) X 255.15 (V)
Horizontal
408.24 mm (16.08 inches)
Vertical
255.15 mm (10.05 inches)
Pixel pitch
0.2835 mm
Viewing angle
160°(vertical)typical,160°(horizontal)
typical
Luminance output
250 cd/m² (typical)
Contrast ratio
1000 to 1 (typical)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
CCFL (2) edgelight system
Response Time
5 ms typical
Color depth
16.7 millions colors
Color Gamut
80% CIE1976 (typical)*
