Dell E193FPc - Page 20

Dell E193FPc
20
Remove bezel:
Disconnect the Key board connector and
remove the bezel
Symbol TPV Part Number Description
4 095G8014 8 21 wire harness
5 KEPC980KED1 Key Board
6 015G8140 2 Main Frame
Remove the small shield:
Remove the screws by Torque B
4
6
5
