Dell E193FPc - Page 21

Dell E193FPc
21
Remove the screw and push the small
shield as the arrowhead direction by
Torque B or by manual
Remove the main frame:
Disconnect the back light connectors
Symbol TPV Part Number Description
7 085G 673 1 SHIELD-INVERTER
Remove the four screws and remove the
main frame By manual or torque =
3kgF.Cm
7
