Dell E193FPc
23
Button the harness A and B by Fix Button
and screw to main frame.
Note: Screw the cable hook as the figure
showed and makes sure the line B is
above line A.
The end
Symbol TPV Part Number Description Symbol TPV Part Number Description
8 95G8018 30590/95G8018 30632
95G8018 30576
095G8018 30594
LVDS 11 CBPC980KLLDR
CBPC980KSLDR
CBPC980KALDR
Main Board
9 052G 1150 C Black
Adhesive
Tape
12 PWPC1942LGD1
PWPC1942SED1
PWPC1942AUD1
Power
Board
10 095G8014 6 19 Wire
Harness
13 052G6025 11772 Mylar
A
B
