Dell E2011H - Monitor Specifications

Bottom View
Monitor Specifications
Flat Panel Specifications

Left view

Right view
Bottom view

Label
Description
Use
1
AC power connector
To connect the monitor power cable.
2
VGA connector
To connect your computer to the monitor using a VGA cable.
3
DVI connector
To connect your computer to the monitor using a DVI cable.
4
Stand lock
To disable the stand release button and lock the stand assembly
using an M3 machine screw.
Model
E2011H
Screen type
Active matrix - TFT LCD
Panel type
TN
Screen dimensions
50.8 cm (20-inches viewable image size)
Preset display area
462.8 (H) x 272.0 (V) mm
Horizontal
462.8 mm (18.22 inches)
Vertical
272.0 mm (10.71 inches)
Pixel pitch
0.277 mm
Viewing angle
160°(vertical)typ,170°(horizontal)typ
Luminance output
250 cd/m ²(typ)
Contrast ratio
1000:1 (typ)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
LED edgelight system
Response Time
5 ms typical
Color depth
16.7 million colors
