Dell E2011H - Environmental Characteristics; Power Management Modes

Environmental Characteristics
Power Management Modes
IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotin
use. This is referred to as Power Save Mode*. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes
functioning. The following table shows the power consumption and signaling of this automatic power saving feature:
The OSD will only function in the normal operation mode. When any button is pressed in Active-off mode, the following message will be displayed:
Activate the computer and the monitor to gain access to the OSD.
* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.
Width
481.51 mm (18.96 inches)
Depth
60.00 mm (2.36 inches)
Stand dimensions
Height
291.66 mm (11.48 inches)
Width
251.10 mm (9.89 inches)
Depth
151.70 mm (5.97 inches)
Weight
Weight with packaging
5.50 kg (12.13 lb)
Weight with stand assembly and cables
4.42 kg (9.73 lb)
Weight without stand assembly
(For wall mount or VESA mount
considerations - no cables)
2.90 kg (6.38 lb)
Weight of stand assembly
1.11 kg (2.45 lb)
Model
E2011H
Temperature
Operating
0°to40°C
Non-operating
Storage: -20°to60°C(-4°to140°F)
Shipping: -20°to60°C(-4°to140°F)
Humidity
Operating
10% to 80% (non-condensing)
Non-operating
Storage: 5% to 90% (non-condensing)
Shipping: 5% to 90% (non-condensing)
Altitude
Operating
4,850 m (15,902 ft) max
Non-operating
12,192 m (40,000 ft) max
Thermal dissipation
85.30 BTU/hour (maximum)
61.42 BTU/hour (typical)
VESA Modes
Horizontal Sync
Vertical Sync
Video
Power Indicator
Power Consumption
Normal operation
Active
Active
Active
Blue
18 W (typical)/25 W (maximum)
Active-off mode
Inactive
Inactive
Blanked
Amber
Less than 0.5 W
Switch off
-
-
-
Off
Less than 0.5 W
NOTE: This monitor is ENERGY STAR
®
-compliant.
