Dell G2724D - Connecting Your Monitor

34 │ Setting up the monitor
Connecting your monitor
WARNING: Before you begin any of the procedures in this section,
follow the Safety instructions.
NOTE: Dell monitors are designed to work optimally with Dell
supplied inbox cables. Dell does not guarantee the video quality and
performance if non-Dell cables are used.
NOTE: Route the cables through the cable-management slot before
connecting them.
NOTE: Do not connect all cables to the computer at the same time.
NOTE: The images are for the purpose of illustration only. The
appearance of the computer may vary.
To connect your monitor to the computer:
1. Turn off your computer and disconnect the power cable.
2. Connect your monitor to the computer with a DisplayPort cable, a USB-C to
DisplayPort cable or an HDMI cable.
Connecting the DisplayPort 1.4 cable
HDMI 1 2
DP 1.4
DP 1.4 DP 1.4
Connecting the USB-C to DisplayPort cable
HDMI 1 2
USB-C
DP 1.4 DP 1.4
