Replacing the Speakers
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before Working Inside Your Computer. After working inside your
computer, follow the instructions in After Working Inside Your
Computer. For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Procedure
1 Use the alignment posts on the computer base to place the speakers in
position.
2 Route the speaker cable through the routing guides on the computer
base.
3 Connect the speaker cable to the system board.
Post-requisites
1 Replace the I/O board.
2 Replace the palm rest.
3 Replace the keyboard.
4 Follow the procedure from step 3 to step 5 in replacing the hard drive.
5 Follow the procedures from step 4 to step 5 in replacing the optical drive.
6 Replace the base cover.
7 Replace the battery.
64
