Removing the Palm-Rest | 33
5 Remove the screws that secure the palm-rest to the system board.
6 Using a plastic scribe gently lift and release the tabs on palm-rest from the slots on
the computer base.
CAUTION: Carefully separate the palm-rest assembly from the display assembly
to avoid damage to the display assembly.
7 Lift the palm-rest off the computer base.
1 screws (7) 2 palm-rest
OM_Book.book Page 33 Tuesday, November 20, 2012 12:43 PM
