Dell Latitude E5570 - Hard Drive Bracket Procedures

Removing the hard drive from the hard drive bracket
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
c. hard drive assembly
3. Pull the hard drive cable to remove it from the connector.
4. Remove the screws that secure the hard drive bracket to the hard drive [1] and lift the hard drive from
the hard drive bracket [2].
10
