Removing the battery
NOTE: If your computer supports the 6-cell battery, it will not support a hard drive.
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. To remove the battery:
a. Disconnect the battery cable from the connector on the system board [1].
b. Remove the screws that secure the battery to the computer [2].
c. Lift the battery away from the computer [3].
4. Unroute the cable from the routing channel [1] and remove the cable from the battery [2].
NOTE: This step is applicable only for a 4-cell battery.
8
