Dell Latitude E5570 - Removing the Optional M.2 SSD; Installing and Removing the PCIe SSD

4. Follow the procedure in After working inside your computer.
Removing the optional M.2 Solid State Drive (SSD)
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
3. To remove the SSD:
a. Remove the screw that secures the SSD to the computer [1].
b. Slide and lift the SSD from the computer [2].
Installing the optional PCIe SSD
1. Insert the SSD clip into the slot on the computer.
2. Tighten the screw to secure the SSD clip to the computer.
3. Insert the SSD into the connector on the computer.
4. Place the SSD bracket over the SSD and tighten the screws to secure it to the computer.
5. Install the:
a. battery
b. base cover
6. Follow the procedure in After working inside your computer.
Removing the optional PCIe SSD
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
