Upgrade Dell EMC Networking N1500 Series Switches
Page 5
6. Reload the switch.
console#reload
Management switch has unsaved changes.
Are you sure you want to continue? (y/n) y
Configuration Not Saved!
Are you sure you want to reload the stack? (y/n) y
NOTE: Using the serial port to update firmware, following output will be
observed. If logged in via telnet or SSH, rebooting switch will close the
connection. Rebooting may take several minutes to complete and the switch
may reboot itself more than once during the upgrade procedure.
Reference platform resetting ...
starting pid 17Rebooting system!
The system is going down NOW!
Sent SIGTERM to all processes
Sent SIGKILL to all processes
Requesting system reboot
U-Boot 2012.10-00244-g9552470cd8 (Feb 20 2018 - 15:54:29)
I2C: ready
BENCH SCREENING TEST1
=========================================
IPROC_XGPLL_CTRL_3: 0x05400000
IPROC_XGPLL_STATUS: 0x80000490
DCO code: 73
=========================================
DEV ID = 0xdb56
SKU ID = 0xb150
DDR type: DDR3
MEMC 0 DDR speed = 667MHz
PHY revision version: 0x00024006
ddr_init2: Calling soc_ddr40_set_shmoo_dram_config
ddr_init2: Calling soc_ddr40_phy_calibrate
C01. Check Power Up Reset_Bar
C02. Config and Release PLL from reset
C03. Poll PLL Lock
C04. Calibrate ZQ (ddr40_phy_calib_zq)
C05. DDR PHY VTT On (Virtual VTT setup) DISABLE all Virtual VTT
C06. DDR40_PHY_DDR3_MISC
C07. VDL Calibration
C07.1
C07.2
C07.4
C07.4.1
C07.4.4
VDL calibration result: 0x30000003 (cal_steps = 0)
C07.4.5
C07.4.6
C07.5
C08. DDR40_PHY_DDR3_MISC : Start DDR40_PHY_RDLY_ODT....
C09. Start ddr40_phy_autoidle_on (MEM_SYS_PARAM_PHY_AUTO_IDLE) ....
C10. Wait for Phy ReadyDone.
DDR phy calibration passed

Dell N1548P Specifications

General

Model	N1548P
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
PoE Power Budget	740 W
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating Temperature	0 °C to 45 °C
Device Type	Switch
Enclosure Type	Rack-mountable
Ports	48 x 10/100/1000
Uplink Ports	4 x 10G SFP+
Routing Protocol	OSPF, RIP, VRRP
Remote Management Protocol	SNMP 1, Telnet, SSH, HTTP, HTTPS
Features	Layer 3 switching, IGMP snooping, Link Aggregation Control Protocol (LACP), Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad
Dimensions	4.32 cm
Storage Temperature	70 °C
Relative Humidity	10 to 90% (non-condensing)
Jumbo Frame Support	9216 bytes
