Upgrade Procedure Dell™ Networking
N2024/N2024P/N2048/N2048P/N3024/N3024F/N3024P/N3048/N3048P
Switches
Page 6
NOTE: Set the image to use as the boot (active) image after the switch
resets. Images on the N2000 and N3000 series switches are named active
and backup.
4. Activate the 6.0.1.3 firmware
console#boot system backup
Activating image backup ..
5. Reload the switch.
console#reload
Management switch has unsaved changes.
Are you sure you want to continue? (y/n) y
Configuration Not Saved!
Are you sure you want to reload the stack? (y/n) y
NOTE: If using the serial port to update the firmware, the following output will be observed. If logged in
via telnet or SSH, rebooting the switch will close the connection. Rebooting may take several minutes to
complete and the switch may reboot itself more than once during the upgrade procedure.
<184> Feb 21 03:17:22 172.25.150.239-1 UNITMGR[107567900]: unitmgr.c(6343) 4845 %% Reset
initiated on unit 1, reason: User Request
Reference platform resetting ...
starting pid 93
syncing filesystems....This may take a few moments
Rebooting system!
The system is going down NOW!
Sent SIGTERM to all processes
Sent SIGKILL to all processes
Requesting system reboot
U-Boot SPL 2012.10-00075-g9766807 (Oct 10 2013 - 13:38:25)
BENCH SCREENING TEST1
=========================================
IPROC_XGPLL_CTRL_3: 0x15400000
IPROC_XGPLL_STATUS: 0x800002b4
DCO code: 43
PASS
=========================================
DEV ID= 0000dc14
SKU ID = 0x0
DDR type: DDR3
MEMC 0 DDR speed = 800MHz
ddr_init2: Calling soc_ddr40_set_shmoo_dram_config
ddr_init2: Calling soc_ddr40_phy_calibrate
C01. Check Power Up Reset_Bar
C02. Config and Release PLL from reset
C03. Poll PLL Lock
C04. Calibrate ZQ (ddr40_phy_calib_zq)
C05. DDR PHY VTT On (Virtual VTT setup) DISABLE all Virtual VTT
C06. DDR40_PHY_DDR3_MISC
C07. VDL Calibration
C07.1
C07.2
C07.4
C07.4.1
C07.4.4
VDL calibration result: 0x30000003 (cal_steps = 0)
