Figure 12. N3048 with 48 10/100/1000BASE-T Ports (I/O-Side)
The I/O-side of each model in the N30xx series includes the following ports:
1 Console port
2 USB port
3 SFP+ Ports
4 Combo Ports
5 10/100/1000BASE-T Auto-sensing Full Duplex RJ-45 Ports
The combo ports are SFP on the N30xx series and 1000BaseT on the N3024F switch.
Figure 13. N30xx Close-up
1 Console port
2 Out-of-Band Management Port
3 USB port
4 Reset Button
5 SFP+ Ports
N30xx Series Overview
23
