N30xx Series Overview
The Dell N30xx switches are stackable Layer 2 (L2) and Layer 3 (L3) Gigabit Ethernet switches and include the following models:
• Dell N3024
• Dell N3024P
• Dell N3048
• Dell N3048P
• Dell N3024F
N30xx Series Hardware Overview
This section contains information about device characteristics and modular hardware configurations for the N30xx Series switches.
All N30xx models are 1U, rack-mountable switches with the following physical dimensions:
• 434.0 x 407.0 x 43.5 mm (W x D x H).
• 17.1 x 16.0 x 1.7 inches (W x D x H).
N30xx Series I/O-Side
The following images show the I/O-sides of the switch models in the N30xx Series.
Figure 11. N3024F with 24 10/100/1000BASE-T Ports (I/O-Side)
5
22 N30xx Series Overview
