Dell Networking S5000 User Manual

Label LED Color/Display Description
• Blue • Port beacon/locator
Port link/activity LED
• Off
• Green solid
• Green blinking
• No link or interface disabled
• Link present and interface
enabled (Ethernet module)
• Port has activity
Module locator beacon LED
• Off
• Blue
• No activity
• Module beacon/locator
Module status LED
• Off
• Green solid
• Yellow
• Module is not powered up
• Module is powered up
• Problem detected with
module
Table 3. Fibre Channel Port/Module LEDs
Label LED Color/Display Description
Port locator beacon LED
• Off
• Blue
• Green
• No activity
• Port beacon/locator
• Fibre Channel mode enabled
Port link/activity LED
• Off
• Green solid
• Green blinking
• No link or interface disabled
• Link present and interface
enabled
• Port has activity
Module locator beacon LED
• Off
• Green
• No activity
• Module beacon/locator
Module status LED
• Off
• Green solid
• Yellow
• Module is not powered up
• Module is powered up
• Problem detected with
module
