Removing the Optical Drive
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the data cable and power cable from the back of the optical drive.
4. Lift the blue tab and slide the optical drive inwards to remove it from the computer.
5. Remove the optical drive from the bracket.
Related Links
Installing the Optical Drive
Installing The Optical Drive
1. Insert the optical drive into the bracket.
2. Lift the blue tab and slide the optical drive outwards to insert it into the computer.
3. Connect the data cable and power cable to the optical drive.
4. Install the cover.
