9. Install the expansion card.
10. Install the drive cage.
11. Install the front bezel.
12. Install the cover.
13. Follow the procedures in After Working Inside Your Computer.
Related Links
Removing the System Board
Removing the Drive Cage
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the front bezel.
4. Remove the data cable and power cable from the back of the optical drive.
5. Slide the drive-cage handle toward the back of the computer into the unlocked position.
6. Rotate the drive cage upward using the handle and lift the drive cage free off the chassis.
30
