Dell OptiPlex 3010 - Installing the Intrusion Switch; Removing the Speaker

Related Links
Installing the Intrusion Switch
Installing The Intrusion Switch
1. Insert the intrusion switch into the chassis rear and slide it outward to secure it.
2. Connect the intrusion-switch cable to the system board.
3. Install the cover.
4. Follow the procedures in After Working Inside Your Computer.
Related Links
Removing the Intrusion Switch
Removing the Speaker
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the front bezel.
4. Remove the drive cage.
5. Disconnect the speaker cable from the system board.
6. Unthread the speaker cable from the fan shelter clip.
16
