Installing The Expansion Card
1. Insert the PCIe x4 card into the connector on the system board and press
down to secure it in place.
2. Insert the PCIe x16 card (if any) into the connector on the system board and
press down to secure it in place.
3. Install the
front bezel
.
4. Install the
cover
.
5. Follow the procedures in
After Working Inside Your Computer
.
16
