Description Values
Audio type 4 Channel High Definition Audio
Audio controller Realtek ALC3246
Internal audio interface Intel HDA (high-definition audio)
External audio interface
One Universal Audio Jack (front)
One Line-out audio port with re-tasking
to Line-in(rear)
Storage
This section lists the storage options on your OptiPlex 5090 Micro.
Your computer supports one of the following configurations:
Table 13. Storage Matrix
Storage 1st 2.5-inch hard drive Single M.2 socket 1st Bootable Device
2.5-inch hard drive Y N 2.5-inch hard drive
M.2 solid-state drive N Y M.2 solid-state drive
Dual M.2 solid-state drive N Y 1st M.2 solid- state drive
M.2 solid-state drive
2.5-inch hard drive/solid-state
drive
N Y M.2 solid-state drive
M.2 Intel Optane 2.5-inch hard drive Y Y 2.5-inch hard drive
Table 14. Storage specifications
Storage type Interface type Capacity
2.5-inch, 5400 RPM, hard-disk drive SATA 3.0 Up to 2 TB
2.5-inch, 7200 RPM, hard-disk drive SATA 3.0 Up to 1 TB
2.5-inch, 7200 RPM, FIPS Self
Encrypting Opal 2.0, hard-disk drive
SATA 3.0 Up to 500 GB
M.2 2230 solid-state drive PCIe Gen 3×4 NVMe, Class 35 Up to 512 GB
M.2 2280 solid-state drive PCIe Gen 3×4 NVMe, Class 40 Up to 1 TB
M.2 2280 solid-state drive PCIe Gen 4×4 NVMe, Class 40 Up to 2 TB
M.2 2280 Opal Self-Encrypting solid- state drive PCIe Gen 3×4 NVMe, Class 40 Up to 1 TB
Hard drive preloaded bracket matrix
Table 15. HDD preloaded bracket cable
3.5-inch Caddy/Bracket No
2.5-inch Caddy/Bracket No
Power adapter
Table 16. Power adapter specifications
Description Values
Type 90 W (35 W CPU) 130 W (35 W CPU)
Diameter (connector) 4.5 mm x 2.9 mm 4.5 mm x 2.9 mm
Input voltage 100 VAC—240 VAC 100 VAC—240 VAC
Input frequency 50 Hz—60 Hz 50 Hz—60 Hz
Input current (maximum) 1.50 A 2.50 A
Output current (continuous) 4.62 A 6.70 A
Rated output voltage 19.50 VDC 19.50 VDC
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F) 0 °C to 40 °C (32 °F to 104 °F)
Storage -40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your OptiPlex 5090 Micro.
Table 17. GPU—Integrated
Controller External display support Memory size Processor
Intel UHD Graphics 630 Two DisplayPort 1.4 ports Shared system memory
10th Generation Intel Core i3/i5/i7
and Intel Pentium
Intel UHD Graphics 730/750 Two DisplayPort 1.4 ports Shared system memory 11th Generation Intel Core i5/i7
Hardware Security
Table 18. Hardware Security
