Expansion Card Tab
Removing the Expansion Card
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the
cover
.
3. Push the release tab on the card-retention latch outward.
4. Pull the release lever away from the PCIe x16 card to release the securing
tab from the dent in the card. Then, ease the card up and out of its
connector and remove it from the computer.
5. Lift the PCIe x1 expansion card (if any) up and out of its connector and
remove it from the computer.
15
