Dell OptiPlex 990 Mini-Tower - 12 Power-Switch Cable; Removing the Power-Switch Cable

12
Power-Switch Cable
Removing the Power-Switch Cable
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the
cover .
3. Remove the front bezel .
4. Remove the optical drive .
5. Disconnect the power-switch cable from the system board.
6. Unthread the power-switch cable from the chassis clips.
7. Unthread the power-switch cable from the chassis clip.
35
