Dell OptiPlex 990 Mini-Tower - Hard Drive; Hard Drive Removal and Installation

6
Hard Drive
Removing the Hard Drive
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the
cover .
3. Remove the data cable and power cable from the back of the hard drive.
4. Press both blue securing-bracket tabs inwards and lift the hard-drive
bracket out of the bay.
5. Flex the hard-drive bracket and then remove the hard drive from the
bracket.
21
