Removing and installing Field Replaceable
Units (FRUs)
The replaceable components in this chapter are Field Replaceable Units (FRUs).
CAUTION: The information in this section is intended for authorized service technicians only.
CAUTION: To avoid any potential damage to the component or loss of data, ensure that an authorized service
technician replaces the Field Replaceable Units (FRUs).
CAUTION: Dell Technologies recommends that this set of repairs, if needed, to be conducted by trained
technical repair specialists.
CAUTION: As a reminder, your warranty does not cover damages that may occur during the courses of FRU
repairs that are not authorized by Dell Technologies.
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Power-supply fan
Removing the power-supply fan
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the stand.
3. Remove the back cover.
4. Remove the system-board shield.
5. Remove the I/O cover.
6. Remove the power-supply unit.
7. Remove the bottom cover.
About this task
The following image(s) indicate the location of the power-supply fan and provides a visual representation of the removal
procedure.
6
76 Removing and installing Field Replaceable Units (FRUs)
