Dell OptiPlex XE - Removing the Optical Drive; Replacing the Optical Drive

Back to Contents Page
Optical Drive
Dell™OptiPlex™XEServiceManual—Desktop
Removing the Optical Drive
1. Follow the procedures in Before Working Inside Your Computer.
2. Disconnect the power and data cables from the optical drive.
3. Pull up the drive release latch and slide the optical drive towards the back of the computer.
4. Lift the optical drive up and away from the computer.
Replacing the Optical Drive
To replace the optical drive, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe®Flash®Player from Adobe.com in order to view the illustrations below.
