Dell P104F002 - Installing the Memory Modules

2. Enter service mode.
3. Remove the SIM card.
4. Remove the microSD card.
5. Remove the base cover.
About this task
The following images indicate the location of the memory modules and provide a visual representation of the removal procedure.
Steps
1. Using your fingertips, spread apart the securing clips on the memory-module slot until the memory module pops up.
2. Slide and remove the memory module from the memory-module slot.
NOTE: Repeat step 1 and 2 if there are two memory modules.
Installing the memory modules
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the memory modules and provides a visual representation of the installation
procedure.
