Removing and installing components
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Recommended tools
The procedures in this document may require the following tools:
Phillips screwdriver #0
Phillips screwdriver #1
Tweezers
Plastic scribe
Screw list
NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and
then place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is
restored when the component is replaced.
NOTE: Some computers have magnetic surfaces. Ensure that the screws are not left attached to such surfaces when
replacing a component.
NOTE: Screw color may vary with the configuration ordered.
Table 1. Screw list
Component Screw type Quantity Screw image
Base cover Captive 6
Battery M2x7 3
CAMM module M2x6
M2x3.5
2
2
Long CAMM module M2x6
M2x3.5
2
4
Interposer board module
NOTE: For models shipped
with memory module
M2x6
M2x5
2
2
2
