3. Install the fans.
4. Install the solid-state drive.
5. Install the battery.
6. Install the base cover.
7. Follow the procedure in After working inside your computer.
Speakers
Removing the speakers
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the fans.
5. Remove the heat sink.
6. Remove the Type-C brackets.
7. Remove the system board.
NOTE: The system board can be removed along with the solid state drive.
About this task
The following image(s) indicate the location of the speakers and provides a visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs)
71
