Keyboard
Removing the keyboard
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the fans.
5. Remove the heat sink.
6. Remove the Type-C brackets.
7. Remove the system board.
NOTE: The system board can be removed along with the solid state drive.
8. Remove the speakers.
9. Remove the power button with fingerprint reader.
About this task
The following image(s) indicate the location of the keyboard and provides a visual representation of the removal procedure.
74
Removing and installing Field Replaceable Units (FRUs)
