Removing The System Board
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the SD memory card.
4. Remove the keyboard.
5. Remove the optical drive.
6. Remove the memory module.
7. Remove the palm rest.
8. Remove the hard drive.
9. Remove the WLAN card.
10. Remove the CPU fan assembly and the heatsink.
11. Disconnect the display cable (1), DC-in cable (2), USB board cable (3), speaker
cable (4), audio board cable (5), and the coin-cell battery cable (6).
12. Remove the screws that secure the system board.
