Installing The Display Assembly
1. Insert the display assembly hinges into their holders.
2. Install the screws that secure both the hinges in place.
3. Connect the LVDS cable to the system board.
4. Align the WLAN antennae routing cable to its holder and connect the
antennae to the WLAN card.
5. Connect the USB board cable.
6. Install the
palm rest
.
7. Install the
keyboard
.
8. Install the
hinge cover
.
9. Install the
battery
.
10. Follow the procedures in
After Working Inside Your Computer
.
53
