About your monitor │ 11
Back view
Back View with monitor stand
Label Description Use
1 VESA mounting holes (100 mm x
100 mm - behind attached VESA
Cover)
Wall-mount the monitor using VESA-
compatible wall mount kit (100 mm x
100 mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases the stand from the monitor.
4 Barcode, serial number, and
Service Tag label
Refer to this label if you need to
contact Dell for technical support.
5 Power On/Off button To turn the monitor on or off.
6 Joystick Use to control the OSD menu. (For
more Information, see Operating your
monitor)
7 Cable-management slot Use to organize cables by routing them
through the slot.
